| Place of Origin: | China |
|---|---|
| Brand Name: | GFUVE |
| Certification: | CE |
| Model Number: | GF112 |
| Minimum Order Quantity: | 1 set |
| Delivery Time: | 5-8 work days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 100 sets 3-4 weeks |
| Active Power Measurement Accuracy: | 0.3%, 0.5% | Energy Measurement Accuracy: | 0.3%, 0.5% |
|---|---|---|---|
| Dimensions (W×D×H) (mm): | 185×67×30 | ||
| High Light: | electrical test equipment calibration,energy meter calibration equipment |
||
| Electrical parameters | |
|---|---|
| Active power measurement accuracy | 0.3%, 0.5% |
| Energy measurement accuracy | 0.3%, 0.5% |
| Power supply | AC 110-264V 50/60Hz |
| Warming-up time | < 5 min |
| Power consumption | ≤5VA |
| Voltage measurement | |
| Range | 0-264V |
| Accuracy | 0.30% |
| Current measurement | |
| Range | 10mA-40A or 10mA-120A |
| Accuracy | 0.3% |
| Phase measurement | |
| Range | 0°-359.9° |
| Resolution | 0.1° |
| Accuracy | 0.5° |
| Frequency measurement | |
| Range | 45-65 Hz |
| Resolution | 0.01Hz |
| Accuracy | 0.05Hz |
| Power factor measurement | |
| Range | 0.4000 ~ +1.0000 |
| Resolution | 0.001 |
| Accuracy | 0.01 |
| Electric energy pulse output | |
| Pulse constant | 900 |
| Energy pulseinput | |
| Input range of pulse constant | 1-25000 |
| Pulse input level | 5V |
| Mechanical parameters | |
| Dimensions (W×D×H) (mm) | 185×67×30 |
| Weight (kg) | 1 (mains) 2 (appendix and bag) |
| Environmental conditions | |
| Working temperature | -10°C to 50°C |
| Working humidity | 5%- 85%RHD |
| Storage temperature | -25°C to 70°C |
| Storage humidity | 5% -95%RHD |
